Track Fitting

Spring Loaded Fitting

FD 5001 Finish: zinc plated yellow, zinc plated clear Breaking Strength: 3000lbs/1361kgs Working Load Limit: 1000lbs/454kgs Weight: 0.20lbs/0.09kgs

FD 5002 Finish: zinc plated yellow, zinc plated clear Breaking Strength: 4500lbs/2041kgs Working Load Limit: 1500lbs/680kgs Weight: 0.21lbs/0.10kgs

Butterfly Fitting

FD 5003 Finish: zinc plated yellow, zinc plated clear Breaking Strength: 1500lbs/680kgs Working Load Limit: 500lbs/230kgs Weight: 0.09lbs/0.04kgs

3-Piece Fitting

FD 5004 Finish: zinc plated yellow, zinc plated clear Breaking Strength: 3000lbs/1361kgs Working Load Limit: 1000lbs/454kgs Weight: 0.18lbs/0.08kgs

Fitting With 2" D-Ring

FD 5005 Finish: zinc plated yellow, zinc plated clear Breaking Strength: 4000lbs/1814kgs Working Load Limit: 1333lbs/605kgs Weight: 0.33lbs/0.15kgs

Fitting With Round-Ring

FD 5006 Finish: zinc plated yellow, zinc plated clear Breaking Strength: 4000lbs/1814kgs Working Load Limit: 1333lbs/605kgs Weight: 0.53lbs/0.24kgs

Track End Fitting

FD 5007 Finish: zinc plated yellow, zinc plated clear Breaking Strength: 3000lbs/1361kgs Working Load Limit: 1000lbs/454kgs Weight: 0.08lbs/0.04kgs

Plate Trailer Hook

FD 5008 Finish: zinc plated yellow, zinc plated clear Breaking Strength: 2200lbs/998kgs Working Load Limit: 735lbs/333kgs Weight: 0.19lbs/0.09kgs

Track End Fitting

FD 5009 Finish: zinc plated yellow, zinc plated clear Breaking Strength: 3969lbs/1800kgs Working Load Limit: 1323lbs/600kgs Weight: 0.17lbs/0.08kgs

Jaw Fitting With Round Ring

FD 5010 Finish: zinc plated yellow Breaking Strength: 5475lbs/2483kgs Working Load Limit: 2300lbs/1043kgs Weight: 0.29lbs/0.13kgs

Single Stud Fitting With Ring

FD 5011 Finish: zinc plated yellow Breaking Strength: 4000lbs/1814kgs Working Load Limit: 1333lbs/605kgs Weight: 0.09lbs/0.04kgs

Heavy Duty Series L Triple Stud Fitting

FD 5012 Finish: zinc plated yellow Breaking Strength: 6500lbs/2950kgs Working Load Limit: 2167lbs/983kgs Weight: 0.23lbs/0.10kgs

Stud Fitting With Pear Shaped Ring

FD 5013 Finish: zinc plated yellow Breaking Strength: 6500lbs/2950kgs Working Load Limit: 2167lbs/983kgs Weight: 0.34lbs/0.15kgs

Track Fitting

FD 5014 Finish: zinc plated yellow Breaking Strength: 6500lbs/2950kgs Working Load Limit: 2167lbs/983kgs Weight: 0.33lbs/0.15kgs

Pan Fitting with Ring and Stud

FD 5015 Finish: zinc plated yellow, black epoxy coating Ring Vertical Breaking Strength: 3000lbs/1361kgs Stud Vertical Working Load Limit: 5000lbs/2268kgs Weight: 0.32lbs/0.15kgs

Pan Fitting with Ring Only

FD 5016 Finish: zinc plated yellow 0° Ring Vertical Breaking Strength: 3000lbs/1361kgs 45° Ring Pull Angle Working Load Limit: 2500lbs/1134kgs Weight: 0.28lbs/0.13kgs

Pan Fitting with Stud Only

FD 5017 Finish: zinc plated yellow 0° Ring Vertical Breaking Strength: 5000lbs/2268kgs 45° Stud Pull Angle Breaking Strength: 2000lbs/908kgs Weight: 0.22lbs/0.10kgs

1" Strap End Mounting Plate

FD 5018 Finish: zinc plated yellow Breaking Strength: 1000lbs/454kgs Working Load Limit: 335lbs/152kgs Weight: 0.05lbs/0.03kgs

1" Strap End Mounting Plate

FD 5019 Finish: zinc plated yellow Breaking Strength: 750lbs/340kgs Working Load Limit: 250lbs/113kgs Weight: 0.06lbs/0.03kgs

1" Strap End Mounting Plate

FD 5020 Finish: zinc plated yellow Breaking Strength: 3500lbs/1587kgs Working Load Limit: 1170lbs/531kgs Weight: 0.22lbs/0.10kgs

Pan Fitting

FD 5021 Finish: zinc plated yellow Breaking Strength: 600lbs/272kgs Working Load Limit: 200lbs/91kgs Weight: 0.6lbs/0.27kgs

FD 5022 Finish: zinc plated yellow, zinc plated clear Weight: 0.34lbs/0.152kgs

Decking Beam Head 3mm

FD 5023 Finish: zinc plated yellow, zinc plated clear Weight: 3.86lbs/1.75kgs

Decking Beam Head 4mm

FD 5024 Finish: zinc plated yellow, zinc plated clear Weight: 4.67lbs/2.12kgs

Slide Adjuster

FD 5025 Finish: zinc plated yellow, zinc plated clear, black epoxy coating Weight: 4.67lbs/2.12kgs



Our tracking are designed to fit securely into E, A and F tracks, and aircraft style seat/logistic track. They are easy to use and long wearing.

Transport and load restraint, ratchet buckle and end fitting, logistic tracking fitting, E, A, F track, aircraft style seat, logistic track.

We supply ratchet tie down, tie down staps, ratchet straps, web lashing, ratchet buckles, cam buckles, over center buckles, wire hooks, j hooks, flat hook, chassis hook.
