Straight Snap Hook, Zinc Plated, Galvanized Straight Snap Hook, Snap Hook, Stainless Steel Snap Hook
Type：Rigging Hardware - Snap Hook

Straight Snap Hook, Zinc Plated

ART. NO. SIZE
mm A
mm C
mm D
mm L
mm SWL
Lbs N.W.
kg/100pcs

FD-700 5X50 25 9 5 50 160 1.75

FD-700 6X60 30 11 6 60 260 2.55

FD-700 8X80 40 13 8 80 400 5.70

FD-700 10X100 50 16 10 100 650 13.60

FD-700 11X120 58 21 11 120 700 18.50

Safety Factor: 4

◇Prev：Snap Hook With Screw, Zinc Plated, Stainless Steel Snap Hook with Screw
◇Next：DIN764 Standard Link Chain

【Straight Snap Hook, Zinc Plated, Galvanized Straight Snap Hook, Snap Hook, Stainless Steel Snap Hook】

Straight Snap Hook, Zinc Plated
ART. NO.	SIZE mm	A mm	C mm	D mm	L mm	SWL Lbs	N.W. kg/100pcs
FD-700	5X50	25	9	5	50	160	1.75
FD-700	6X60	30	11	6	60	260	2.55
FD-700	8X80	40	13	8	80	400	5.70
FD-700	10X100	50	16	10	100	650	13.60
FD-700	11X120	58	21	11	120	700	18.50
Safety Factor: 4
