NACM84/90 Standard Link Chain, High Test Chain NACM84/90 (G43)
Type:Chain - Welded Link Chain



NACM84/90 Standard Link Chain
High Test Chain NACM84/90 (G43)
Nominal
Size
Material
Diameter
Working Load
Limit
Proof Test
Min
Breaking Force
Min
Inside
Length
Inside
Width
MM IN MM IN KG LBS KN LBS KN LBS MM IN MM IN
7 1/4 7 0.276 1180 2600 16.6 3750 33.1 7500 31.5 1.24 9.8 0.38
8 5/16 8 0.315 1770 3900 21.6 4900 43.2 9700 32.8 1.29 11.2 0.44
10 3/8 10 0.394 2450 5400 33.8 7600 67.6 15200 35 1.38 14 0.55
13 1/2 13 0.512 4170 9200 57.1 12900 114.2 25700 45.5 1.79 18.2 0.72
